Prentex 9500 PAV

Features include:

• A 100% stainless steel pressure vessel, ASME Code stamped and registered with the National Board of Boiler and Pressure Vessels
• A touchscreen control panel for easy operation with a minimum of input required
• A hinged and bolted PAV cover and compact stainless steel cabinet designed to fit against the wall, or in a corner, and/or under overhead shelves
• Precision stainless steel sample rack with a set of 10 precision spun sample pans
• Space Efficiency: the PAV9500 occupies only 650 mm by 430 mm of space and requires only 790mm of overhead clearance.
• Light Weight: the PAV9500 weighs under 180 pounds so it can sit on a standard laboratory counter-top (Does not require special low bench)

Energy Efficient

The PAV 9500 operates using almost any standard electrical supply and is so efficient that it actually saves energy

• Requires no special wiring
• Draws less than 525 watts during warm up and less than 60 watts of electricity when at a stable temperature
• Is available in 100-125 volt, 10 Amp versions and 208-252, 5 Amp versions
• Is the only PAV system available that can operate with a standard low cost back up supply during a power outage

Safe and Supported

The PAV 9500 system meets all suggested safety requirements and is easy to maintain, especially with our customer support policies

• Meets all AASHTO R28, ASTM6521 and EN14769 apparatus requirements
• For safety the PAV 9500 cannot operate in excess of its design limits
• Is supported by both telephone and email/fax so most problems can be easily corrected on-site
• Comes with a one-year parts and workmanship guarantee
